เครื่องค้นหา ตำแหน่งเซอร์กิตเบรกเกอร์ Circuit Breaker Finder Socket Tester Finder 220V AC EU Plug

รายละเอียดสินค้า

เครื่องค้นหา ตำแหน่งเซอร์กิตเบรกเกอร์ Circuit Breaker Finder Socket Tester Finder 220V AC EU Plug

>> เช็คสต๊อคสินค้า <<

Circuit breakers are very convenient safety devices used to protect an over-current situation in your electrical system. Find specific breaker or fuse that controls your wal socket or plugs, lightings, etc.
Included Lamp Socket & Outlet Adapters makes this tool more dynamic.

Features:

• Automatically and quickly finds correct breaker or fuse.
• Quickly and easily identify conditions of circuit socket.
• Transmitter Works on 220VAC
• Operating temperature: 0 ~ 50
• Circuit Breaker Finder Socket Tester
• Automatically adjust the sensitivity
• Visual and auditory instructions
• Flashlight function
• Low battery indication

Operation: Locating a Circuit Breaker or Fuse

1. Keep the pillar at left on the MS5902-T
2. Plug the MS5902-T into the receptacle.if there is a candescent light fixture,please install a socket adapter before make sure the switch is OFF.then plug the MS5902-T into the socket adapter,turn the switch on at one time.(Socket adapter need purchase additional)
3. Go to the circuit breaker panel box.
4. Turn the MS5902-R on,the red LED is light.
5. Place the chapiter of the MS5902-R directly onto the circuit breaker or fuse.
6. Slide the chapiter of the MS5902-R down each breaker along both sides of the panel .Then the MS5902-R will beep frequently as it denote the relative signal strength.
7. Move the MS5902-R down each breaker once more. On the third pass, the MS5902-R will beep ,the red LED will quench and the green LED will light only at the circuit Breaker powering the MS5902-T.
8. Push the breaker off and check that the LED on the MS5902-T in the outlet is off to confirm you have found the correct breaker or buse.



วิธีการใช้งาน

Test Socket: Keep the pillar at right on the MS5902-T.
Please contradistinguish nameplate on the MS5902-T.



• General Specifications:
• Power Supply: 1 * 9V battery/6F22(not included)
• Package Size: 26.5 * 16 * 6.5cm / 10.5 * 6.3 * 2.5in
• Package Weight: 264g/9.3oz

Package List: H13061US

• 1 * Mastech MS5902 Automatic Circuit Breaker Finder Socket Tester

รับประกันสินค้า 1 เดือน

ข้อมูลเพิ่มเติม

น้ำหนัก	0.4 kg
