รายละเอียดสินค้า
โหลดเซลล์แอมพลิไฟล์ รองรับ 4 เซนเซอร์ พร้อมจอแสดงผล Digits LED Display Weighing Controller Load cells Indicator 1-4 Load Cell
The instrument provides isolated auxiliary power(regularly 5V/80mA) which allows 1-4 loadcells connection directly. Up to 6 outputs control are available for group ingredients weighing or fast/slow weighing; Data/Peak value holding function for choice.
Features:
- High precision, steady performance and easy operation.
- Dual LED nixie tube digits for display, clear for reading.
- 1-4 load cell signals input and 2 RELAY output alarms.
- The instrument has functions of clearing zero & PV modification.
- Work with various pressure sensor and weight sensor.
- Suitable for for weight control, auto accumulation/mean for up/down batch control, etc.
Specifications:
- Model: LM8-RRD(4 Digits)
- Display: LED Display
- Power Supply: LM8-RRD: 220V/110V AC; LH86-RRD: 90-260V AC/DC
- Accuracy:0.2%F.S±2dgt
- Power Consumption: ≤5VA
- Sampling Rate: ≤16 times/second
- Input: Regular: mV(Load Cell), 1-4 pcs Load Cell
- Output: 2 RELAY
- Relay: Open Contract 250V AC 3A or 30V DC 3A COSφ=1
- Auxiliary Power: DC 5V
- Item Size: 95 * 85 * 46mm / 3.74 * 3.35 * 1.81in
Package List:
- 1 * Weighing Controller
- 2 * Bracket
- 1 * User Manual (English)
รับประกันสินค้า 3 เดือน
