รายละเอียดสินค้า
ม่านแสงนิรภัย เซนเซอร์ม่านแสง 2 เมตร Safety Light Curtain Sensor 154 Beam Photocell Switch Light Curtain (สินค้า Pre-Order)
Elevator Lift Door Safety Security Edge Infrared Door
Elevator Safety Infrared Screen Doors Protecting System Elevator Door Photocell Sensor Switch with CE Certificate Approved
Technical Parameters
- Beams Number: 154 beams (infrared)
- Sensors Number: 32 pairs
- Sensors Interval: 58.8 mm
- Beams Center Points Interval: 10.5mm/11.5mm
- Scanning Form: Line by line
- Response Time: 61msec(relating to detecting points of scanning cycle)
- Detecting Height: 25-1860mm
- Detecting Range: 0~5.0m moving door
- Light Immunity: 80,000lux(visible light)
- Allowable Deviation Angle: ≤10°
- Allowable Deviation Position: Vertical: ±10mm/7° | Horizontal: ±5mm/5°
- Protecting States: Cable fault | Power fault
- Current Consumption: Less than100mA
- Power Adapter: MODEL258 or 368
- Protection Grade: IP65 standard
- Ambient Temp.: -20°C~ +70°C
- Storage Temperature: -40°C~ +80°C
- Other functions: One transmitter is shielded after 120s’ blocking
- Indicator: Power (green LED) | System fault/beams blocked(orange LED)
- Shell Material | Aluminum alloy surface of anodizing (black)or matt spray
- plastic(black)
- Shell Cover (light filter): Embedded installation of infrared penetrating for blocking
- off non-infrared
- Authentication: CE(EMC)
- Working Voltage: 12V(8V~30V)
- Power supply: 220VAC or 24VDC
