เครื่องวัดฉนวน เครื่อวัดค่าฉนวน Megger Tester High Resistance Meter Model AT683 100kΩ~10TΩ (สินค้า Pre-Order)
>> แจ้งความต้องการสินค้า <<
The AT683 High Resistance Meter is an MCU controlled measuring instrument for direct readout of resistance and current. The voltage applied to the device under test (DUT) is programmable from 1 to 1000 volts. A pass/fail indicator provides a visual display of test results based on a preset limit.
The AT683 High Resistance Meter is designed for measuring very high resistance and related parameters of insulation materials, electronic components, and electro-mechanical components.
รายละเอียดสินค้า
- Parameter: Leakage current and insulation resistance
- Output Voltage: AT683: (NC)1V~1000VDC
- Accuracy:
- Measurement Range
– 100kΩ~10TΩ
– 10V: 100kΩ~100GΩ
– 100V: 1MΩ~1TΩ
– 1000V: 10MΩ~10TΩ - Max Reading: 9999
- Range: Automatic and Manual
- Speed: 55 times/second,15 times/second,3 times/second
- Adjustment: Open-circuit Zero-Adjust for each range
- Result Display: Show, current, resistance, peak value, and sorting result
- Charging Timer: 999.9s
- Comparator: 30 sets record,GD/NG Beep: GD,NG,OFF setting.
- Interface: RS-232C interface Handler interface (AT682SE optional interface)
- Others: VFD four color high-definition screen,keypad lock and data hold function
GENERAL FEATURES
- Power Supply: Voltage: 198VAC~240VAC Frequency: 50Hz Power: Max 30VA
- Dimension & Weight: 264(Width)mmx107(Height)mmx350mm(Depth) 5kg
Accessories
- ATL507: Test Clip
- ATL108: RS232 Interface Cable
รับประกันสินค้า 6 เดือน
