รายละเอียดสินค้า
เครื่องตรวจเช็คความร้อนระบบอินฟาเรท กล้องอินฟาเรทตรวจเช็คความร้อน Professional Handheld Thermal Imaging Camera Portable Infrared Thermometer IR Thermal Imager (สินค้า Pre-Order)
>> แจ้งความต้องการสินค้า <<
Performance InfraRed 32×31 pixels Imagers Thermometer
DT-9868 is a Professional InfraRed 32×31 pixels Imager Thermometer with 2.2” color TFT LCD display; a microSD memory card for capturing images (BMP) for viewing on your PC; providing fast, easy and accurate readings for most surfac
iRTP software
for InfraRed Thermometer
Meterbox iRTP smartview software provides a professional report with table and chart, details including data analysis, alarm indication, fault doubt share, inspector management, application scene, fast inspection, scene mode, equipment maintenance and quality inspection.
The smart choice; The default usage scene; Data analysis; Table and chart display; Alarm indication; Fault doubt share; Inspector management; Fast inspection; Scene mode; quipment maintenance; Quality inspection
Features:
- 2.2″ TFT 320×240 Pixels color LCD display;
- IR temperature measurement with resolution 32×31 pixels;
- Image Capture Frequency 9Hz;
- Thermal Sensitivity (NETD) ≤150 mK;
- Hot Spot and Cold Spot Tracking;
- Visual Camera & Images Capture (BMP);
- MicroSD memory card;
- Date/time setup controls, Adjustable emissivity & trigger lock;
- Li-ion rechargeable battery;
- SB interface to smartphone / PC;
- Language selection: English, Chinese;
- Meterbox IRTP & cloud service;
Technical
| Imaging and optical data | |
| Thermal sensitivity (NETD) | 0.15 (0.27) @ 1Hz and 100 |
| Image frequency | 9Hz |
| Detector data | |
| Detector type | Uncooled hyper-thin pyroelectric ceramic |
| Spectral range | 6.5-14μm |
| IR resolution | 32×31 pixels |
| Display | 2.2″ TFT 320×240 pixels color LCD display |
| IR temperature measurement | |
| Object temperature range | -20 to +300-4 to +572) |
| Accuracy | ±2% ±2 as tested |
| Spot | Hot spot and cold spot tracking |
| Emissivity adjustable | 0.10~1.0 adjustable |
| Micro SD memory card | MAX. support 8GB |
| Field of view | 38°x 38° |
| Color palettes | Hot metal/ironbow/rainbow/rainbow high contrast/grayscale |
| Image storage format | Standard BMP, including measurement data, on memory card>1000 pictures |
รับประกันสินค้า 6 เดือน
