• Mounting hole size : 16mm
• LED voltage: 36V
• Switch specifications : 3A/250VAC

• Waterproof pushbutton switch

• Mounting diameter: 16mm

• Switch combination : 1NO

• Head shape: Flat

• Lamp type : Ring luminated

• Tail configuration : Connection terminal(2.8×0.5mm)

• Contact resistance : <50m

• Insulation resistance : >1000m

• Dielectric intensity : 2000VAC

• Ambient temperature : -20~+55

• Machanical life : 500,000 cycles

• Electrical lif : 50,000 cycles

• Panel thickness : 1~10mm

• Nut torque : 5~14Nm

• Operation pressure : About 3~5N

• Degree of protected : IPP67, IK10

• Button : Nickel plated brass / Stainless stell

• Enclosure : Nickel plated brass / Stainless stell

• Base : PA66

• LED life : 40000 hours
• LED Color : RED
