รายละเอียดสินค้า
เซ็นเซอร์วัดอัตราการไหลของน้ำ วัสดุ POM เกรดสำหรับอาหาร food Grade Water flow sensors MJ-A68-1 Black flow level meter,1/8 Diameter
The principle of operation
Liquid level sensors by the composition of reed switches and float, reed switch encapsulated in the guide, and a ring magnet is equipped in the float, when the float moves up and down with the measured of liquid level,and the internal magnet to attract magnetic reed switch contact action,so that it can to detect the liquid level position.
ข้อมูลเซ็นเซอร์วัดอัตราการไหล:
- Model name: MJ-A68-1
- Working Voltage Rating: DC 5~24V
- Max working current 15mA
- Withstand Water Pressure: ≤0.35MPa
- Flow range: 0.2-6L/Min
- Insulating resistance: >100MΩ
- Flow pulse: 1L water = 1380Hz ±10%
- Pulse duty cycle: 50% ±10%
Installation instructions
1.Should be mounted away from the inlet, or switch will caused malfunction by the fluctuations in intake.
2.The load must be controlled circuit capacity with float switch contacts to match.
3.The proportion of liquid to be measured must be greater than the proportion of float.
4.Float action points have been ordered by the customer requirements adjusted at the
factory, Please do not adjust the float position
Routine maintenance
Periodically clear the guide rod and float on the dirt
(as the media cycle may be). Check for the loose buckle.
รับประกันสินค้า 1 เดือน
