Product Features:

• Dual display for both set temperature and process temperature
• Size,  72*72mm
• Universal input, support 10 different types of  thermocouples and RTD inputs by customers selected at panels.
• Auto-tune function can find the best PID parameter automatically
• Displays temperature in Celsius
• Four digits LED display can go up to “9999”
• Can be powered by either DC or AC power source
• Uses it for Kiln,Furnace,Oven,Incubator temperature control
• Uses it in heating control as well as for cooling control
• It is used in various industries to control and monitor process temperatures

Specifications:

• Input type:
  • TC: K, E, S, R, J, T, B, WRe3-WRe25.

  • RTD: Pt100, Cu50

  • DC voltage: 0~5V, 1~5V,0~10V.

  • DC current: 4~20mA
• Input range: K (0~400ºC)
• Display: Two lines, Four digits. °C.
• Display Resolution: 1°C, 1°F, or 0.1°C, 0. 1°F, with Pt100
• Accuracy: ±0.5% or ±1 unit of full input range
• Control mode: PID, On-Off
• Output mode:
  • Relay contact: 3A at 240 VAC.

  • SSR: 12VDC,

  • Current: 4~20 mA

  • Voltage: 0~10V
• Alarm: Upper-limit bias alarm
• Power consumption:
• Power supply voltage rating: 85~265VAC/50~60Hz
• Dimensions: Rex-C700  72*72*110mm

Cautions:

• Only clean the instrument when power off.
• Please use a soft cloth or cotton paper to clean up the stain on the display.
• Do not clean up or touch the display by hard matters in case of  any scrath.
• Never use sharp & hard matters such ass screwdrivers or ball pan to touch the buttons on the panel,in case of any scrath or damage.
